Electrical Circuit Virtual Lab
Electrical Circuit Virtual Lab > To verify Kirchhoff’s Laws: Kirchhoff’s Current Law, Kirchhoff’s Voltage Law > Simulator

Volt
R1 ohm
R2

ohm
R 3

ohm
R1 : 8 ohm
R2 : 3 ohm
R3 : 6 ohm
Vin : 30 Volt

Write your Answer

Voltage(in volt) Current(in amp) Power(in watt)
R1
R2
R3
